IMAGE SENSOR 1/3" CMOS (RGB)
NUMBER OF EFFECTIVE PIXELS Approx. 2.1 million pixels
SCANNING METHOD Progressive
LENS 2.4x optical zoom lens (electric drive)
FOCAL LENGTH 2.55 (W) - 6.12 mm (T)
F-NUMBER F1.2 (W) - F1.8 (T)
DIGITAL ZOOM 4x
HORIZONTAL VIEWING ANGLE1 124.3° (W) - 50.5° (T)
VERTICAL VIEWING ANGLE 66.9° (W) - 28.4° (T)
DAY/NIGHT SWITCH Yes
I/R CUT FILTER Automatically removable infrared-cut filter
MIN. SUBJECT ILLUMINATION - DAY (COLOR) 035 lux (F1.2, shutter speed 1/30 sec.)
MIN. SUBJECT ILLUMINATION - NIGHT (MONOCHROME) 0 lux (F1.2, shutter speed 1/30 sec., IR light on) .002 lux (F1.2, shutter speed 1/30sec., IR light off)
FOCUS MODES Auto/One-shot AF/Manual/Fixed at infinity
SHOOTING DISTANCE Day Mode: 0.3 m (12 in.) - infinity Night Mode: 0.3 m (12 in.) - infinity
SHUTTER SPEED 1 - 1/16000 sec.
EXPOSURE Auto/Auto (Flickerless)/Auto (Shutter-priority AE)/Manual (Shutter Speed, Aperture, Gain)
WHITE BALANCE Auto/Light Source/Manual Light Source: Daylight Fluorescent/White Fluorescent/Warm Fluorescent/Mercury Lamp/Sodium Lamp/ Halogen Lamp Manual: One-shot WB/R Gain/B Gain
METERING MODE Center-Weighted/Average/Spot
EXPOSURE COMPENSATION 9 levels
SMART SHADE CONTROL Auto: 3 Levels
Manual: 7 Levels
AGC LIMIT 6 levels
IMAGE STABILIZER N/A
PAN ANGLE RANGE 344° (-217° - +127°)
TILT ANGLE RANGE 93° (-3° - +90°)
ROTATION ANGLE RANGE 344° (±172°)
IR ILLUMINATION RANGE 30 m (98.4 ft.) (When using 24 V AC, PoE+) 15 m (When using PoE/12 V DC)
MOVING SPEED N/A
VIDEO COMPRESSION METHOD JPEG, H.264
BIT RATE CONTROL Target Bit Rate: 64-16384 kbps
VIDEO SIZE JPEG, H.264: 1920 x 1080, 960 x 540, 480 x 270 1280 x 720, 640 x 360, 320 x 180 1280 x 960, 640 x 480, 320 x 240
SIMULTANIOUS VIDEO STREAMS N/A
VIDEO QUALITY JPEG, H.264: 10 levels
FRAME RATE JPEG, H.264 (1920 x 1080): 30fps
MAXIMUM FRAME RATE JPEG, H.264 (1920 x 1080): 30fps
ADSR: AREA-SPECIFIC DATA SIZE REDUCTION Number of Specified Areas: Max. 8 windows
I-FRAME INTERVAL 0.5/1/1.5/2/3/4/5 sec.
SIMULTANEOUS CLIENT ACCESS Max. 30 Clients + 1 Admin Client - H.264: Max. 10 Clients
CAMERA CONTROL Administrator, Authorized user, Guest user (level of control varies depending on user)
ACCESS CONTROL User authority (user name and password), Host Access Restrictions (IPv4, IPv6)
ENCRYPTED COMMUNICATIONS SSL/TLS, IPsec
IEEE 802.1X EAP-MD5, EAP-TLS, EAP-TTLS, EAP-PEAP
ONVIF Version Profile S, Profile G
IPv4 PROTOCOL TCP/IP, UDP, HTTP, FTP, SNMPv1/v2c/v3 (MIB2), DHCP, DNS, AutoIP, mDNS, ARP, ICMP, POP3, NTP, SMTP, RTP/RTCP, RTSP, SSL/TLS, IPsec, ONVIF, WV-HTTP (Canon proprietary)
IPv6 PROTOCOL TCP/IP, UDP, HTTP, FTP, SNMPv1/v2c/v3 (MIB2), DHCP, DNS, AutoIP, mDNS, ARP, ICMP, POP3, NTP, SMTP, RTP/RTCP, RTSP, SSL/TLS, IPsec, ONVIF, WV-HTTP (Canon proprietary)
AUTO IP Yes
AUDIO COMPRESSION METHOD G.711 µ-law (64 kbps)
AUDIO COMMUNICATION METHOD Full-duplex (two-way) - Echo cancellation function compliant RTP, Sound Transfer Protocol by Canon
AUDIO FILE PLAYBACK Available (audio files can be played back when an event is triggered by the intelligent function or external device input.)
PRIVACY MASK Number of registration: Max. 8 places, Number of mask colors: 1 (select from 9 colors)
VIEW RESTRICTION N/A
PRESETS Number of registers: Max. 20 positions (+Home Position) Number of Preset Tour Route: Max. 1
INTELLIGENT FUNCTION - VIDEO Detection Types: Moving Object Detection, Abandoned Object Detection, Removed Object Detection, Camera Tampering Detection, Passing Detection, and Intrusion Detection
INTELLIGENT FUNCTION - AUDIO Volume Detection, Scream Detection
Volume Detection Max. 15
EVENT TRIGGER TYPE External Device Input, Intelligent Function (Video), Intelligent Function (Audio), Timer, Day/Night Switch Number of Linked Events: 2 Linked Event Conditions: AND, OR (whether or not there is a sequence to events)
IMAGE UPLOAD FTP/HTTP/SMTP (e-mail)
EVENT NOTIFICATION HTTP/SMTP (e-mail)
ON-SCREEN DISPLAY Available
IMAGE CROPPING FUNCTION Digital PTZ Cropping sizes: 640 x 360/512 x 288/384 x 216/256 x 144/128 x 72 640 x 480/512 x 384/384 x 288/256 x 192/128 x 96
ENHANCED DIGITAL ZOOM N/A
DAYLIGHT SAVINGS TIME Available
CUSTOM SETTINGS TBD
NETWORK TERMINAL LAN x 1 (RJ45, 100Base-TX (auto/full-duplex/half-duplex))
AUDIO INPUT TERMINAL F3.5 mm (F0.14 in.) mini-jack connector (monaural) Switch LINE IN/MIC IN in the setting page.
EXTERNAL DEVICE I/O TERMINAL Input x 2, Output x 2
ANALOG VIDEO OUT N/A
MEMORY CARD TYPE SD Memory Card, SDHC Memory Card, SDXC Memory Card Compatible
MEMORY CARD RECORDED CONTENT Log, Video (Event, Manual, ONVIF, Timer, Upload)
MEMORY CARD RECORDED FRAME RATE Frame Rate: Max. 1 fps (JPEG) Max. 30 fps (H.264)
TEMPERATURE Operating Temperature Range (including direct sun exposure) AC, PoE+: -50°C - +55°C (-58°F - +131°F) DC, PoE: -10°C - +55°C (+14°F - +131°F) Start-up Temperature Range (including direct sun exposure) AC, PoE+: -30°C - +55°C (-22°F - +131°F) DC, PoE: -10°C - +55°C (+14°F - +131°F))
HUMIDITY Humidity: 5% - 85% RH (without condensation)
TEMPERATURE -30°C - +60°C (-22°F - +140°F)
HUMIDITY 5% - 90% RH (without condensation)
PoE IEEE802.3af Class 0 (PoE) / IEEE802.3at (PoE+)
AC ADAPTER PA-V18 (100 - 240 V AC) (sold separately)
EXTERNAL POWER SOURCE 24 V AC/12 V DC
WITH PoE Max. approx. 10.2W
WITH AC ADAPTER AC Adapter PA-V18: Max. approx. 12.5 W (100 V AC) Max. approx. 12.6 W (240 V AC)
WITH 12VDC Max. approx. 11.2W
WITH PoE + Max. approx. 20.1W
WITH 24VAC+ Max. approx. 20.9W
DIMENSIONS (H x W x D) 111 x 102 x 214 mm (4.37 x 4.02 x 8.43 in.) (camera body only) - Length when joint fully extended (D): 402 mm (15.83 in.)
MOUNTING POSITION Ceiling mount/Surface mount
HEATER Built-in
WEIGHT Approx. 2600 g (5.74 lb.)
OUTDOOR READY Yes
IP RATING IP66
VANDAL RESISTANT No
IMPACT RESISTANCE N/A
