MAIN UNIT SPECS
IMAGING TECHNOLOGY Copy Press and Gemini Duplex Technology from Canon.
ENGINE RESOLUTION LED, 600 x 1200 dpi, 85/106/125/141/180 lpi
PRINT SPEED 6330/6270/6220/6180
Up to 320/266/216/177 (Letter)
Up to 167/143/116/95 (Ledger)
OPTIMAL MONTHLY PRINT VOLUME 1,000,000 - 10,000,000 (Letter images)
USER INTERFACE TYPE Intuitive 15" touch screen user interface
CHARACTERIZATION Multiple and customizable views help ensure a productive and controlled workflow. Queue Manager, Job Scheduler, system status overview, multiple queues, job definition and selection options, bundle printing
PAPER HANDLING Maximum: 12.6" x 19.2" (320 mm x 488 mm)
Minimum: 8" x 8" (203 mm x 203 mm)
Optional: 7" x 10" (178 mm x 254 mm) with Statement-sized option
PAPER SIZE 8" x 8.2" (203 mm x 208 mm) to 13.8" x 19.7" (350 mm x 500 mm) with optional PIM FlexA1
PAPER INPUT (STANDARD) 4 paper trays (2 x 1700 sheets + 2 x 600 sheets)
OPTIONS Second and third paper input module (standard size or PIM Flex-A1)
MAXIMUM PAPER CAPACITY 24,000 Letter sheets from 4 standard and 8 optional paper trays (20lb Bond) with Duo Tray Option to increase Letter input capacity
PAPER WEIGHT Plain Paper: 13 lb. Bond to 110 lb. Cover (50 to 300 gsm)
Coated Media: 20 lb. Bond to 90 lb. Cover3 (80 to 250 gsm)
Light-Weight Media: 12lb Bond to 13 lb Bond (45 - 50 gsm) with the optional light-weight media module
OUTPUT ACCESSORIES
HIGH CAPACITY STACKER Capacity 6000 sheets - 20 lb bond (80 g/m2)
(2 stacks x 3000 sheets each).
FUNCTIONALITY All paper input sizes and weights are supported including tabs. Supports OEM output to third party finishing solutions
OPTIONAL Up to 3 Stackers can be configured inline, offering 18,000 sheets output capacity
SET FINISHER (OPTIONAL)
FINISHER Capacity 4000 sheets letter 20 lb Bond (80g/m2)
SIZES The following paper sizes can be stacked (and stapled): all (custom) sizes between:
- long edge:10.8" to 12" (275 to 306 mm )
- 12" - short edge: 8.2" x 8.7" (208 to 220 mm)
- Number of staples in a set: 1 or 2
STAPLING POSITIONS Corner portrait or landscape, side
STAPLING CAPACITY 100 sheets plain paper (20lb Bond)
CONNECTIVITY
NETWORK HARDWARE 10/100/1000 Mb, 1Gb Ethernet
NETWORK PROTOCOL

TCP/IP (LPR/LPD, socket), SMB static/auto IP (via DHCP) SNMP v1-v3 (printer MIB, private MIB, Job monitoring MIB), IPP

SUPPORTED PDLS (SUPPORTS AUTOMATIC LANGUAGE SENSING) APPE (Adobe® PDF Print Engine)
Adobe® PostScript® 3TM/ streaming PostScript®
PPML/GA Level 1
PPML versions 1.5,2.1 and 2.2
PDF 1.7
PCL 6
Xerox® PPP support
IPDS(options)
Instant switching from IPDS or SRA PCL6 to PostScript 3/PDF/PCL 6
Streaming behavior for all PDLs
