PRODUCT INFO
Model Name | imageRUNNER 1643i |
Type | Monochrome A4 Laser Multifunctional |
Functions | Print, Copy, Scan, Send |
Operation Panel | 5" TFT LCD WVGA Color Touch Panel |
Imaging System | Canon Dual Custom Processor (Shared) |
Image Server Memory | 1.0 GB RAM |
Network Interface Connection | 1000Base-T/100Base-TX/10-Base-T, Wireless LAN (IEEE 802.11 b/g/n), NFC (only 1643iF), Wi-Fi Direct Connection |
Other Interface | USB 2.0 (Host) x2, USB 2.0 (Device) x1 |
Max Mailboxes Supported | LDAP (50)/Local (300)/Speed Dial (281) |
Max Copy Reservation | Up to 600 x 600 |
Scanning Resolution | Up to 600 x 600 |
Printing Resolution | 600 × 600 |
Warm Up Time | From Power On: 14 seconds or Less2 From Sleep Mode: 4 Seconds or Less |
Power Requirements | 120-127 V, 60 Hz, 7.1 A |
Power Consumption | Maximum: 1,500 W Sleep Mode: 0.9W or Less5 |
Plug | NEMA 5-15P |
Dimension | 18-7/8" x 23-1/2" x 17-3/4" (480 mm x 595 mm x 452 mm) |
Installation Space | 27-3/8" x 43-1/2" (694 mm x 1105 mm) |
Weight | Approx. 41.9 lb. (19 kg) 3 |
Basic Copy Features | Preset R/E Ratios by Area, Paper Setting, Favorite Setting, Two-Sided, Density Adjustment, Original Type Selection |
Special Copy Features | Two-sided Original, Sort, Job Build, N on 1, Different Size Originals, Density Adjustment, Original Type Selection, Sharpness, Erase Frame, Copy ID Card |
Environmental Features | ENERGY STAR® Certified Rated EPEAT® Gold1 |
Advanced Box
Common Protocol | File: FTP (TCP/IP), SMB (TCP/IP) Email: SMTP, POP3 |
Max. Number of Concurrent Connections | One |
Memory Media
Standard | USB |
Scan Specifications
Network TWAIN Scan | Standard |
Network Scan Utility | ScanGear MF |
Copy/Print Speed (BW/Color)
Letter | Up to 45 ppm |
Legal | Up to 36 ppm |
Copy Specifications
First Copy Time | As fast as 6.0 Seconds (via Platen) |
Multiple Copies | Up to 999 |
Magnification | 25% - 400% (1% Increments) from Platen Glass |
Preset Reductions | 25%, 50%, 64%, 78% |
Preset Enlargements | 129%, 200%, 400% |
Acceptable Originals | Sheet, Book, 3-Dimensional Objects |
Maximum Original Size | Up to 8-1/2" x 1 |
Standard Paper Capacity | 550-sheet Paper Cassette |
Optional | 550-sheet PAPER FEEDER PF-C1 (up to 3) |
Manual Bypass | 100-sheet Stack Bypass |
Maximum Paper Capacity | 2,300 Sheets |
Output Paper Capacity | Maximum: 250 Sheets |
Output Sizes
Cassette | Letter, Legal, Statement, Executive |
Bypass | Letter, Legal, Statement, Executive, Custom size (3" x 5" to 8-1/2" x 14"), Envelope (C5/DL/ COM-10/Monarch) |
Acceptable Paper Weights
Cassette | 16 lb. Bond to 32 lb. Bond (60 to 120 g/m2) |
Bypass | 16 lb. Bond to 73 lb. Cover (60 to 199 g/m2) |
Duplexing
Duplexing | Duplexing Automatic Document Feeder |
Paper Size | 4-1/8" x 5" to 8-1/2" x 14" |
Paper Weight | Simplex: 13 lb. to 28 lb. Bond (50 to 105 g/m2) Duplex: 17 lb. to 28 lb. Bond (64 to 105 g/m2) |
Security Features
Standard | Authentication: Department ID Authentication and embedded Universal Login Manager with uinFLOW Online/Online Express,4 IP/ Mac Address Filtering, IPSEC, TLS Encrypted Communication, SNMP V3.0, IEEE 802.1X, IPv6, SMTP Authentication, POP Authentication before SMTP, Secure Print, Encrypted PDF, Device Signature |
Optional | Authentication: uniFLOW |
Estimated Toner Yield | (Estimated Yield @ 5% Coverage) 20,500 Images |
